The new model 57IR, a true embodiment of sports wheels

The balance of lightweight design and strength is a crucial element for sports wheels. The model 57IR is a reexamination of the original concept that embodies the brand ethos of gramLIGHTS. In line with the evolution of tire grip, we have adopted a spoke shape that is resistant to flex, distortion, and twist, ensuring durability even under harsh driving conditions. At the same time, we focused on the shape of the spoke roots at the center, advancing lightweight design through bold machining that creates notches. While featuring a simple design, it promises a uniquely different driving experience.

No app required!
Easily experience AR with
just your smartphone!

>No app required! Easily experience AR with just your smartphone!

* Click here for a video on how to use AR WHEEL SIMULATOR.

Spec

Product Name

57IR

Size

15inch

Construction Method

Cast 1pc. Wheel

Safety Standards

JWL+R Spec 2

Color

Admiral Blue(2ZZ)
Glass Black(6XZ)

Optional Parts

Size / Spec

SIZE :

P.C.D. :

SIZE INSET Hub
Clearance
(mm)
HOLE P.C.D. HUB
BORE
(φ)
DRILL
(φ)
COLOR PRICE DISK
PROTRUSION
(mm)
LOAD
(lbs)
CODE
15x7J 48 (23) 4 100 65 29-13 6XZ ¥39,000 1.5 1,102 584757048026XZ
15x7J 48 (23) 4 100 65 29-13 2ZZ ¥39,000 1.5 1,102 584757048022ZZ
15x7J 35 (36) 4 100 65 29-13 6XZ ¥39,000 1.5 1,102 584757035026XZ
15x7J 35 (36) 4 100 65 29-13 2ZZ ¥39,000 1.5 1,102 584757035022ZZ
15x7J 25 (46) 4 100 65 29-13 6XZ ¥39,000 1.5 1,102 584757025026XZ
15x7J 25 (46) 4 100 65 29-13 2ZZ ¥39,000 1.5 1,102 584757025022ZZ

Caution
※Hub clearance is the measurement used with the standard setting center cap.

Features

Sharp and powerful 2x5 spokes

The gramLIGHTS 57IR features a seemingly simple 2x5 design. Its slender and sporty form provides a visual sense of lightness, while the side taper catches the light, emphasizing the strength of its three-dimensional shape. This creates an overall sense of stability.
The spoke lines arc gracefully, expressing depth and strength.

Center design

The center circle, positioned at the heart of the design, deliberately forgoes unnecessary decorations to convey a rugged impression. The combination of the boldly notched machining line at the spoke roots and the downward-sloping spoke design towards the center strongly expresses the serious nature of a sports wheel visually.

Embossed gramLIGHTS logo

The gramLIGHTS logo is embossed between the spokes, asserting that this wheel combines both lightweight design and strength.
